Titanium Grade 2 Tubes

Titanium CP Grade 2 welded tube and ASTM B348 UNS R50400 seamless tube supplier in India

The softest and most ductile titanium is Grade 2, and Neeka Tubes is a well-known producer and supplier of these tubes. Titanium Grade 2 Seamless Tubes find its application in condenser tubes, heat exchangers, cryogenic tanks, pickling baskets, airframe components, and CPI equipment. Numerous successful applications have resulted from the high strength, low weight ratio, and exceptional corrosion resistance of Titanium Grade 2 Welded Tubes and their associated alloys. Titanium Grade 2 EFW Tubes are commonly utilized in applications that demand exceptional corrosion resistance in a variety of aggressive conditions, out of the four commercially pure (C.P.) titanium grades. Between classes 1 and 3, these titanium grade 2 ERW tubes offer exceptional strength, outstanding formability, and resistance to corrosion.

Metals containing a combination of titanium and other chemical components are known as titanium grade 2 round tubes. These Grade 2 Titanium Square Tubes are used to construct machined parts with mechanical qualities and purity levels that fall between those of Grade 1 and Grade 3 standards. Commercially Pure Grade 2 Rectangular Titanium Tubes are among the most widely available unalloyed Titanium grades. These Titanium Grade 2 Electropolish Tubes offer excellent mechanical qualities, low weight, thermal stability, and resistance to corrosion. At 882.5 degrees Celsius (1620.5 degrees Fahrenheit), Pure Titanium Grade 2 Hexagonal Tubes experience an allotropic transition from the hexagonal close-packed alpha phase to the body-centered cubic beta phase.

Manufacturer of ASTM B348 UNS R50400 tubes provide customized shapes and form such as square/ round/ rectangle as per MTC EN 10204 3.1/3.2

Titanium Alloy Gr 2 Tubes Specifications

Specifications	ASTM B163 ASTM B516 ASME SB163 ASME SB516
Dimensions of ASTM B348 Gr2 UNS R50400 tube	ASTM, ASME and API
Titanium grade 2 tubes Size	6 mm OD x 0.7 mm to 50.8 mm OD x 3 mm thk.
Schedule	SCH20 SCH30 SCH40 STD SCH80 XS SCH60 SCH80 SCH120 SCH140 SCH160 XXS
ASTM B348 gr2 welded tube sizes	Size: 5.0 - 1219.2 mm Thickness : 0.5 - 20mm Length: 1m to 6m or custom
Titanium Gr 2 seamless tube sizes	Size: 4 - 219mm Thickness : 0.5 - 20mm Length: 1m to 6m or custom
ASTM B348 gr2 seam welded tube surface treatment	anti rust oil hot galvanized cold galvanized Black painting varnish paint
Grade 2 titanium alloy tube manufacturing types	Seamless ERW LSAW Welded EFW CDW Fabricated DOM CEW
Manufacturing technique	Hot formed Cold Formed Cold drawn
Cp Ti grade 2 rectangular tube finish	Cold Finish Bright Polished Annealing Mill finish Hair line Mirror Brush Pickling Custom Sand blast
Form	Round Square Rectangular Hydraulic
Length Ti grade 2 tube	Single Random Double Random Cut Length
Packaging	Wooden Boxes PE Fabric Bundles Crates Special crates Bundles
End	Plain End Beveled End Treaded
Grade 2 Titanium square tube SWG	10 Swg 12 Swg 14 Swg 16 Swg 18 Swg 20 Swg
Documentation offered	Copy of Invoice MIT Copy of Packing List indicating details Country of Origin Certificate
Application of Grade 2 Titanium tube	Dairy tube Oil tube Gas tube Fluid tube Boiler tube for Chemical Industry

Stockist of titanium Grade 2 UNS R50400 seam welded tube OD range from 6 mm x 0.7 mm to 50.8 mm x 3 mm as per ASME B36.10 standard

Grade 2 Titanium Alloy Tube Chemical Composition

Grade	Ti	C	Fe	H	N	O	Al	V
Ti Grade2	99.2 min	0.1 max	0.3 max	0.015 max	0.03 max	0.25 max	–	–

Exporter of ASME SB 348 Gr 2 round tube in Mumbai, Check dimensions

Titanium Grade 2 Tubing Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Titanium Gr. 2	4.5 g/cm3	1665 °C (3030 °F)	Psi – 49900 , MPa – 344	Psi – 39900 , MPa – 275	20 %

Equivalent Grades for Grade2 Titanium Seamless and Welded Tubes

STANDARD	WERKSTOFF NR.	UNS
Titanium Grade2	3.7035	R50400

Find standard and non standard sizes of Grade 2 titanium alloy square tube at distributor price

Titanium Alloy Grade 2 Tubes Price List

• Gr.2 seamless Titanium Tubes
  US $10-178 / Piece ( FOB Price)
• seamless Tube astm b338 alloy
  US $20-100 / Kilogram ( FOB Price)
• titanium seamless Tubes Gr.2
  US $20-50 / Kilogram ( FOB Price)
• ASTM b338 Gr2 Titanium welded Tube
  US $30-60 / Kilogram ( FOB Price)
• sa338 alloy Gr.2 seamless Tubes
  US $2200-4800 / Ton ( FOB Price)
• Gr.2 Titanium alloy seamless Tubes manufacturer
  US $25-60 / Kilogram ( FOB Price)
• ASTM b338 Gr.2 Welded Tube
  US $15-112 / Kilogram ( FOB Price)

Titanium Grade 2 Seamless / Welded Tubes Application Industries

• Off-Shore Oil Drilling Companies
• Power Generation
• Petrochemicals
• Gas Processing
• Specialty Chemicals
• Pharmaceuticals
• Pharmaceutical Equipment
• Chemical Equipment
• Sea Water Equipment
• Heat Exchangers
• Condensers
• Pulp and Paper Industry

Titanium Alloy Gr 2 tube Pressure Rating

Tube O.D.(in.)	Wall Thickness of tube (inches)
	.028	.035	.049	.065	.083	.095	.109	.120
	Working Pressure (psig)
1/8	7900	10100
1/4	3700	4800	7000	9500
5/16		3700	5400	7300
3/8		3100	4400	6100
1/2		2300	3200	4400
3/4			2200	3000	4000	4600
1				2200	2900	3400	3900	4300
